Liner Hanger Services

Ciscon provides comprehensive liner hanger services and solutions designed to ensure well integrity and optimal performance. Our liner hangers and related tools are engineered to provide superior reliability in even the most challenging well environments.

With our experienced team and innovative technology, we deliver liner hanger solutions that meet the diverse needs of the oil and gas industry.

Superior Design Features

Our liner hangers feature unique designs that maximize performance and reliability in the wellbore.

Comprehensive Equipment Options

We provide a full range of liner hanger equipment including packers, seal assemblies, and setting tools.

Specialized Cementing Tools

Our cementing manifolds and plugs ensure effective cement placement for secure liner installation.

Liner Hanger Equipment
Our Capabilities

Comprehensive Liner Hanger Solutions

We offer various types of liner hanger products to meet your specific well requirements

RPSB Liner Hanger

Our model RPSB hanger offers superior performance through innovative design:

  • Unique tongue and groove slip design for superior performance
  • Reduced potential cone collapse due to unique slip and hanger body design
  • Protected slip while running in
  • Hydraulic set (mechanical set also offered)
  • Hanging capacities beyond standard slip and cone liner hangers
RPSB Liner Hanger

Setting Tool Features

Our setting tools are designed for reliable operation:

  • Run on model D setting tool (mechanical release)
  • Solid body and welded body construction
  • Designed to maximize circulating area
  • 8rd and buttress threads are standards
  • L80 and P110 are standards
Setting Tool Features

Liner Top Packers

Our liner top packers provide exceptional sealing capabilities:

  • Weight set packers (except the HLT-H)
  • Can be set at any time during cementing operation using a tamping dog assembly
  • Element is secured in the set position by an internal lock ring
  • Built with slips for higher hanging capabilities
Liner Top Packers

Liner Tieback Packer

Our tieback packers ensure reliable connections:

  • Run in a second trip after cementing and liner setting tool retrieval
  • Bottom seal nipple stings into an existing tie back on top of a previously set liner
  • Hydraulic or mechanical set design
  • High temperature and high pressure design
  • Anti-swab packer element design
  • Full bore packer
Liner Tieback Packer
Tieback Seal Assembly
Additional Solutions

Specialized Liner Hanger Components

Our range of liner hanger components is designed to provide complete and reliable liner installation solutions.

Tieback Seal Assembly

  • Consists of seal mandrel, seal units, half mule shoe, spacers as required by tie back length, and a locator
  • Mule Shoe configuration aids in stabbing and provides smooth re-entry for wire line equipment
  • Seal units to meet any well environment
  • Manufactured from alloy steel to meet liners properties
  • Optional cement port available

Hydraulic Running Tool

  • Provides right hand rotation of string in tension, compression or neutral position
  • After actuating the hydraulic piston, the tool can be retrieved by straight pull
  • Secondary release mechanism: approximately 6 turns with left hand rotation
  • Precludes accidental release

Cement Manifold

  • Suspends the drill pipe weight from the top drive assembly
  • Heavy duty swivel permits manipulation of the work string without breaking down the cement line
  • Connects the cementing line to the running string during liner cementing operation
  • Retains the drill pipe plug for release after the cement job
  • External valve directs fluid flow either above or below the plug
  • Ball drop sub available for use with a hydraulic setting tool
Specialized Equipment

Complementary Liner Hanger Tools

Our comprehensive range of tools ensures successful liner installations

Swivel Top Drive Cement Manifold

  • Constructed with drill pipe retainer and swivel mechanism below the elevator
  • Heavy duty swivel permits manipulation of the work string without breaking down the cement line
  • Fluid flow through the manifold is directed either above or below the plug by external valve
  • Retains the drill pipe plug in position for release after the cement job
  • Ball drop sub available for use with a hydraulic setting tool
Swivel Top Drive Cement Manifold

Alternative Running Tool

  • Provides right hand rotation of string with tool in tension, compression or neutral position
  • After actuating the hydraulic piston, the tool can be retrieved by straight pull
  • Secondary release mechanism: approximately 6 turns with left hand rotation
  • Precludes accidental release
  • Enhanced design for reliability in challenging well conditions
  • Compatible with various liner hanger systems
Alternative Running Tool
Quality Assurance

Our Quality Commitment

We maintain stringent quality control standards for all our liner hanger equipment and services to ensure reliable performance in the field.

API Certified Equipment

All components meet or exceed API specifications for quality and reliability.

Rigorous Testing Protocols

Each component undergoes comprehensive testing before deployment.

Certified Technicians

Our field personnel are certified and experienced in liner hanger operations.

Detailed Documentation

Complete records for all equipment and operations ensure traceability.
